Brief Introduction
This new generation of WiFi access control keypad reader supports This new generation of WiFi access control keypad reader supports glass touch panel,classic & durable.Fully potted waterproof IP66 for outdoor.The visual operation menu is easy for the users to operate.It is easy to add,delete user/check the door status/query the open records by mobile phone.
Parameters
| Model | SD2-T |
| Material | Metal case, tempered glass touch panel |
| Waterproof | IP66 |
| Power | DC10-24V |
| Input | EM 125KHz丨Mifare 13.56MHz （Mobile NFC) 丨Wiegand 26-58 bit |
| Wiegand 26-58 Bit丨4bit,8bit,virtual card number | |
| User Capacity | 5000 card pin users (include 10 anti-duress users) |
| Environmental | Temperature:-20℃~﹢60℃ |
| Humidity:10%-99% | |
| Dimension | 131*55*20mm |
| Weight | 0.65kg |
Main Features
OLED screen display丨Users management by smartphone app丨Open remotely through app丨Door magnetic detection
Multiple authentication ways丨Query the open records by app or thourgh screen display
Copy & transfer the user card/code data to another device丨Modify the user information
Set the unlocking time in access mode丨Wiegand reader mode丨2-9 multi-user authentication
OTA online upgrade 丨keyboard backlight,LED indicator,buzzer sound can be set
Model
- SD2-T EM 125KHz
- SD2-T MF 13.56MHz (Mobile NFC)
- SD2-T DM EM&Mifare 125KHz & 13.56MHz
