Brief Introduction
This new generation of WiFi fingerprint access control keypad reader supports Tuya app remote management. The metal case and tempered glass touch panel is classic and anti-vandal.Waterproof IP66 for outdoor.Supports remote-control by smartphone app.It is easy to add delete user/check the door status/query the open records/open remotely by smartphone.
Parameters
| Model | SF20-T |
| Housing | Metal case, touch screen |
| Waterproof | IP66 |
| Power | DC10-24V |
| Input | EM 125KHz Wiegand 26-44bit丨Mifare 13.56MHz ( Mobile NFC) Wiegand 26-44,56,58bit |
| Output | EM Wiegand 26-44bit丨Mifare Wiegand 26-44,56,58bit |
| User Capacity | 100 or 500 fingerprint users + 10,000 card/pin code users |
| Environmental | Temperature:-20℃~﹢60℃ |
| Humidity:10%-99% | |
| Dimension | 131*55*20mm |
| Weight | 0.65kg |
Main Features
Users management by app丨Open remotely by app丨Set the open time
Door status check with app丨Multiple authentication ways丨Query the open records by app
Visitor users丨Data transmisstion of card & PIN users
Model
- SF20-T EM 125KHz
- SF20-T MF 13.56MHz (Mobile NFC)
- SF20-T DM EM&Mifare 125KHz & 13.56MHz
