Brief Introduction
This new generation of fingerprint access control keypad reader has attractive appearance of metal case and tempered glass touch panel which is anti-vandal and classic.Waterproof IP66 for outdoor installation. Supports multiple ways of authentication: fingerprint/card/PIN code multi-users/temporary guest users.Also supports user card and PIN code data copy.
Parameters
| Model | SF20 |
| Housing | Metal case, touch screen |
| Waterproof | IP66 |
| Power | DC10-24V |
| Input | EM 125KHz Wiegand 26-44bit丨Mifare 13.56MHz ( Mobile NFC) Wiegand 26-44,56,58bit |
| Output | EM Wiegand 26-44bit丨Mifare Wiegand 26-44,56,58bit |
| User Capacity | 100 or 500 fingerprint users + 10,000 card/pin code users |
| Environmental | Temperature:-20℃~﹢60℃ |
| Humidity:10%-99% | |
| Dimension | 131*55*20mm |
| Weight | 0.65kg |
Main Features
Semiconductor fingerprint scanner丨Support Admin add/delete fingerprint/card丨Visitor users
Anti-duress users丨Data transmission of user card & user code丨Interlock丨Multiple users
Switch mode & Access mode丨Sound & LED light status can be set by the uesrs
Model
- SF20-EM 125KHz
- SF20-M 13.56MHz (Mobile NFC)
- SF20-DM EM&Mifare 125KHz & 13.56MHz
